Основные
Вес	1.147,588 kg
Width inner ring	278,994 mm
Shaft diameter	340 mm
Динамическая грузоподъемность, радиальная	2.548.859,68 N
Статическая грузоподъемность, радиальная	4.545.362,272 N
Housing height	1.003,3 mm
Length base	1.219,2 mm
Complete unit float	S3BCH-340MM-FL
Complete unit held	S3BCH-340MM-HD
Housing designation	PH-319
Center height	469,9 mm
Base width	317,5 mm
Base height	82,55 mm
Base hole distance 1 min	631,825 mm
Base hole distance 1 max	685,8 mm
Base hole distance 2	190,5 mm
# of mounting bolts	8
Mounting bolt diameter	38,1 mm
Cartridge float bearing	S3BC-340MM-FL
Cartridge held bearing	S3BC-340MM-HD
Cartridge	S3C-1400
Outside diameter cartridge	704,85 mm
Grease capacity	14,969 kg
Cartridge weight	703,069 kg
Bearing float	S3B-340MM-FL
Bearing held	S3B-340MM-HD
Bearing weight	322,051 kg
Динамическая грузоподъемность, осевая	96.788,48 N
Limiting speed	700 1/min
Outside diameter bearing	615,95 mm
Width outer ring	157,988 mm
Base hole distance 3 min	898,525 mm
Base hole distance 3 max	952,5 mm
Lenght through bore	431,8 mm
Bearing Group	1400 Grp
