Основные
Вес	201,399 lbs
Width inner ring	3 7/8 in
Shaft diameter	5 7/16 in
Динамическая грузоподъемность, радиальная	80.163 lbf
Статическая грузоподъемность, радиальная	123.970 lbf
Housing height	15 1/2 in
Length base	22 in
Complete unit float	S1BCH-507-FL
Complete unit held	S1BCH-507-HD
Housing designation	PH-9
Center height	7 1/8 in
Base width	7 in
Base height	1 9/16 in
Base hole distance 1 min	18 1/2 in
Base hole distance 1 max	19 1/2 in
Base hole distance 2	4 3/4 in
# of mounting bolts	4
Mounting bolt diameter	7/8 in
Cartridge float bearing	S1BC-507-FL
Cartridge	S1C-508
Length through bore	6 9/16 in
Outside diameter cartridge	11 in
Grease capacity	1,8 lbs
Cartridge weight	81,1 lbs
Bearing float	S1B-507-FL
Bearing held	S1B-507-HD
Bearing weight	32,4 lbs
Динамическая грузоподъемность, осевая	712 lbf
Limiting speed	1.780 1/min
Outside diameter bearing	9 1/2 in
Width outer ring	2 3/16 in
Cartidge held bearing	S1BC-507-HD
Housing group	508 Grp
